TLIB documentation
TLIB uses a thread-safe global, tl_errno, to store the last error that occured in the thread currently executing. Most functions and methods will return either 0 or a valid, positive value on success, and -1 (or NULL) in case of failure. On failure, programmers can check the value of tl_errno against the error values.
To help identify the errror, the tlError() functions return a string that describes the error. If tl_set_verbose() is enabled, TLIB will spontaneously produce error messages to the standard output as they occur.
An important feature of the TLIB error management is its ability to detect errors in constructors/destructors. Every constructor and destructore of TLIB classes sets the tl_errno global to TL_NO_ERROR on success, or an error value otherwise.
#include "tlVision.h"
Go to the source code of this file.
Defines | |
| #define | TL_ERRNO_MSG(msg, errno) { (tl_errno = errno); if (tlVerbose > 0) {tlError (msg); }} |
Enumerations | |
| enum | tl_errors { TL_NO_ERROR, TL_ERROR, TL_ERROR_INVALID_FORMAT, TL_ERROR_GEOMETRY, TL_ERROR_NULL_POINTER, TL_ERROR_INDEX_OUT_OF_BOUNDS, TL_ERROR_MAX_REACHED, TL_ERROR_ALLOCATION_FAILED, TL_ERROR_NOT_IMPLEMENTED, TL_ERROR_FILE_IO, TL_ERROR_FILE_NOT_FOUND_OR_CORRUPT, TL_ERROR_NOT_REQUIRED, TL_ERROR_NOT_FOUND, TL_ERROR_NOT_AVAILABLE, TL_ERROR_NOT_IN_IMAGE, TL_ERROR_STACK_OVERFLOW, TL_ERROR_TIMEOUT, TL_ERROR_THREAD, TL_ERROR_TIMER, TL_ERROR_RESOURCE_NOT_AVAILABLE, TL_ERROR_CONFIG_FAILED, TL_ERROR_GRAB_FAILED , TL_ERROR_NA } |
Functions | |
| int * | tl_errno_location () |
| Function that returns the address of the tl_errno variable. | |
| void | tl_errno_destructor (void *) |
| errno dectructor | |
| void | tl_errno_once () |
| errno initializer | |
| void | tlError () |
| void | tlError (const char *str) |
| void | tlError (int errno) |
| void | tlError (int errno, const char *str) |
| #define TL_ERRNO_MSG | ( | msg, | |||
| errno | ) | { (tl_errno = errno); if (tlVerbose > 0) {tlError (msg); }} |
Sets the tl_errno global and displays an error message to the standard output if tl_set_verbose() is enabled.
| enum tl_errors |
Valid error values used by all TLIB methods and functions.
| TL_NO_ERROR | Indicates that no error occured during processing. This is the default return value for most TLIB functions. |
| TL_ERROR | Indicates that a generic error occured. |
| TL_ERROR_INVALID_FORMAT | Indicates that an operation cannot be performed on the given image or object format. Either the image format conflicts with another argument, or the operation cannot be performed on this particular format. In the case of tlDigitizer, it also indicates that a particular acquisition format is not available. |
| TL_ERROR_GEOMETRY | Indicates that there is a geometric mismatch between the entities being processed. This typically happens when two TLIB objects with different sizes are applied a transformation. |
| TL_ERROR_NULL_POINTER | Indicates that an invalid pointer was used. This is typically returned when a NULL argument is given as an argument to a TLIB method. |
| TL_ERROR_INDEX_OUT_OF_BOUNDS | Indicates that an array is being referenced at a position bigger than its size. |
| TL_ERROR_MAX_REACHED | Indicates that some data has reached its maximum allowed value. This can be the number of physical devices opened at the same time, or the maximume number of features detected in a blob extraction performed by tlBlob. |
| TL_ERROR_ALLOCATION_FAILED | Indicates that memory allocations failed. |
| TL_ERROR_NOT_IMPLEMENTED | Indicates that a method or function is not currently implemented. |
| TL_ERROR_FILE_IO | Indicates that an error occured in a file read/write operation. |
| TL_ERROR_FILE_NOT_FOUND_OR_CORRUPT | Indicates that a necessary file (an image file, a library or a configuration file) is either missing or corrupt. Check the filename. |
| TL_ERROR_NOT_REQUIRED | Indicates that a given operation will leave the data unmodified. While it is more a warning than an actual error, it should be avoided in real-time vision programming. |
| TL_ERROR_NOT_FOUND | Indicates that an object or feature was not found by the correlation routines. |
| TL_ERROR_NOT_AVAILABLE | Indicates that an operation or feature is not available in the current context. This usually means that the function is not available for a particular implementation of a hardware interface. |
| TL_ERROR_NOT_IN_IMAGE | Indicates that a point is not within the image boundaries. This error can be safely ignored in most TLIB high-level methods, as these check the validity of all arguments before applying them. |
| TL_ERROR_STACK_OVERFLOW | Indicates that a stack overflow exception was caught. This error typically happen during a recursive call to the object recursive extraction routines (see tlObject). It is possible to prevent it by asking your compiler to increase the default stack size. |
| TL_ERROR_TIMEOUT | Indicates that an operation timed out. This is usually thread related (see tlThread.h) |
| TL_ERROR_THREAD | Indicates a thread related error (see tlThread.h) |
| TL_ERROR_TIMER | Indicates a timer related error (see tlTimer.h). |
| TL_ERROR_RESOURCE_NOT_AVAILABLE | Indicates that a hardware resource is not available. This can mean that the device is not present, is already opened, or that there is a conflict. |
| TL_ERROR_CONFIG_FAILED | Indicates that a hardware resource could not be configured with the given parameters. |
| TL_ERROR_GRAB_FAILED | Indicates that image acquisition failed. Depending on the source, it could mean that the hardware was not open or has been disconnected, or that an image (or video) file is missing. |
| TL_ERROR_NA | Indicates that the requested operation cannot be applied to the given arguments. |
| void tlError | ( | int | errno, | |
| const char * | str | |||
| ) |
Display an error message corresponding to a given error. The error is printed on the standard output, preceded by the str argument.
| errno | the error number | |
| str | preceding string |
| void tlError | ( | int | errno | ) |
Display an error message corresponding to a given error. The error is printed on the standard output.
| errno | the error number |
| void tlError | ( | const char * | str | ) |
Display an error message corresponding to the last error that occured in the calling thread. The error is printed on the standard output, preceded by the str argument.
| str | preceding string |
| void tlError | ( | ) |
Display an error message corresponding to the last error that occured in the calling thread. The message is printed on the standard output.
